Video Controller

●Dual network card devices, which can distinguish between internal and external networks and save IP resources

●Eight 100 MHz RJ45 ports can be connected to 16-way parking cameras.

●Supporting parking statistics and controlling the display of remaining parking spaces on LED screen

●Large-capacity distributed storage, 4 3.5-inch hard disk bits, 16 TB storage capacity, 16-channel 2 Mbps stream can be recorded for 30 days

●Dual network card devices, which can distinguish between internal and external networks and save IP resources

●Eight 100 MHz RJ45 ports can be connected to 16-way parking cameras.

●Supporting parking statistics and controlling the display of remaining parking spaces on LED screen

●Large-capacity distributed storage, 4 3.5-inch hard disk bits, 16 TB storage capacity, 16-channel 2 Mbps stream can be recorded for 30 days

system parameter
processor	High Performance ARM A9 Digital Media Processor
operating system	Embedded Linux Operating System
Input and output parameters
Network Video Input	Up to 16 parking spaces for camera access
Alarm input	4-way alarm input
Alarm output	4-way alarm output
Interface parameters
RS232 interface	One RS232 interface
RS485 interface	Three RS485 interfaces
network interface	Eight internal 100M Ethernet interfaces and four external 10/100/1000M adaptive Ethernet interfaces
Optical port	1 external light port
Functional parameters
data storage	Supports storage of snapshots and videos from parking cameras, with maximum support of 4 hard disks
Data upload	Supporting data upload to central platform and video stream forwarding
General specification
Power Supply	AC220V, Standard City Electricity
power	<150< Span= > > tile
mechanical properties	Size: 370mm (width)110mm (depth)500mm (height)
work environment	Working temperature - 20 ~60 C, working humidity 10%~90%.
